The topics of papers given at these meetings present a snapshot of the state of electron microscopy at the time. A brief look at three of these meetings shows the evolution of the technology and its applications over a year period.

In the brief twelve-year span of tothe physical sciences overtook the biological sciences at EMSA meetings, judging solely on number of papers presented. A large part of this development is probably due to the emergence of the scanning electron microscope inwhich made examination of the surface of bulk specimens possible for the first time.

With no similar dramatic development in biological microscopy, the balance shifted. The willingness and ability of scientists to modify these expensive, complicated, instruments to meet their own needs is evident throughout this year span.

Indeed, many of the improvements in commercial instruments had their origins in the laboratories of the microscopists, not in the manufacturer's labs. This type of feedback from users had to be one of the major indicators to manufacturers as to what they should develop next.

The incorporation of a large number of these improvements in sample stages and detectors led eventually to the commercial analytical and environmental microscopes of today.

Most important for our discussion is the fact that materials science as a discipline was recognized by electron microscopists after the emergence of the SEM. It might be said that the SEM helped to establish and solidify materials science as a field of its own.

Of the 27 papers devoted to topics that would fall under the heading of materials science but, notably, were not grouped or named as such16 discussed lattice defects such as stacking faults or dislocations, 9 dealt with the effects of irradiation on materials, 1 examined fatigue crack nucleation, and 1 described surface treatment of materials.

These materials topics were based almost exclusively on analysis of thin foils using the TEM. In addition, 5 papers discussed high voltage electron microscopy, 13 dealt with the relatively new SEM, and 6 dealt with electron diffraction applications, mainly selected area diffraction in the TEM.

A look at the titles of some of these papers is revealing: The computer not only processes the video information, but also generates the raster for the SEM. Broers of the Thomas J. The title reveals that the field emission gun FEG that was to provide a brighter electron source for instruments in the s was already being developed.

The title demonstrates that microscopists were engaged in modifying their commercial instruments to fit their own needs, in this case the need to examine samples at elevated temperatures.

Braski, Oakridge National Lab, Tennessee. Braski modified a Hitachi HUB electron microscope, giving it three ion pumps and two titanium sublimation pumps, which require no vacuum grease. Improvement in vacuum was a concern, and once again the researcher modified his instrument to attain it.

Materials Analysis Company Model S. Now that the SEM was established as a valuable tool, manufacturers such as the Materials Analysis Company were looking for ways to enhance its analytical power by adding existing detectors, like the electron microprobe.

The spirit of innovation that led researchers to modify complicated, expensive equipment for their own needs is also evident. In many cases, these homemade innovations made their way back to the manufacturer and eventually into commercial instruments.

While papers on biological applications still represented the majority of those presented at this meeting with a total ofthe physical sciences mainly materials science were catching up with a total of papers. The concern with developing new instrumentation, and with learning to understand the mechanisms behind the images that came from these instruments, is evident in the high number of papers devoted to those topics.

A brief survey of papers: Frank of the Cavendish Laboratory in Cambridge, England. He noted that high-resolution images generally contain a lot of noise from the substrate and the photographic grain.

Using mathematical techniques to separate the noise from the signal results in higher resolution. Sometimes this requires additional microscopy, such as taking a micrograph of the substrate by itself in order to subtract out its noise contribution from the final substrate-plus-sample image.

Crewe of the University of Chicago. Crewe maintained that there were two avenues toward the improvement of scanning microscopy: Nixon of the Engineering Department of Cambridge University.

This paper may have provided some hope to Crewe in his request for a higher-resolution display. Siegel of Cornell University. Ong, details an attempt to make a combined instrument by mounting a second electron gun for SEM purposes below the viewing chamber.

An alternative approach toward the same end was presented by K. Other papers dealt with improving SEM sample mounts, vacuum chambers, specimen heating stages, and cryogenic specimen cooling stages. At this meeting papers were presented in the physical sciences versus for the biological sciences.Therefore the authors used transmission electron microscopy (TEM) with samples prepared in two ways, the focused ion beam (FIB) method and the tripod method to study the structure between Si 1− x Ge x and sapphire substrate and Si 1− x Ge x itself.

The question is What is resolution in the context of SEM(Scanning Electron Microscopy). The answer should be related to the spot size of electron beam and the wavelength of electrons.
